Processador

Socket AM4, Processadores AMD Ryzen™ 2ª Geração/Ryzen™ com gráficos Radeon™ Vega/Ryzen™ 1ª Geração

Dimensões

30,5 x 23,4 cm

Formato Board

ATX

Chipset

AMD B450

Memória RAM

Processadores AMD Ryzen™ 2ª Geração/ Ryzen™ com gráficos Radeon™ Vega/ Ryzen™ 1ª Geração | 4x DIMM, Max. 64GB, DDR4 3200(O.C.)/3000(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory | Arquitetura de Memória Dual Channel

Expansibilidade

AMD Ryzen™ 2nd Generation/ Ryzen™ 1st Generation Processors | 1x PCIe 3.0/2.0 x16 (x16 mode) | AMD Ryzen™ with Radeon™ Vega Graphics Processor

Gráficos

Integrated in the AMD Ryzen™ with Radeon™ Vega Graphics Processors | Suporta saída Multi-VGA: Portas HDMI/DVI-D | Suporta HDMI 2.0b com resolução máxima de 4096x2160 @ 60 Hz | Suporta DVI-D com resolução máxima de 1920x1200 @ 60 Hz

Armazenamento

AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation Processors | 1x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) | 2x SATA 6Gb/s port(s) | AMD B450 chipset | 4x SATA 6Gb/s port(s)

LAN

1x Gigabit LAN Realtek® RTL8111H

Áudio

Realtek® ALC887-VD2 8-Channel High Definition Audio CODEC

Ligações USB

AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation | 2x USB 3.1 Gen 1 port(s) (2 at back panel, , Type-A) | AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation | 1x USB 3.1 Gen 1 port(s) (1 at back panel, , USB Type-C) | AMD B450 chipset | 2x USB 3.1 Gen 2 port(s) (2 at back panel, , Type-A) | AMD B450 chipset | 2x USB 3.1 Gen 1 port(s) (2 at mid-board) | AMD B450 chipset | 6x USB 2.0 port(s) (2 at back panel, , 4 at mid-b

Interfaces

1x PS/2 keyboard/mouse combo port(s) | 1x DVI-D | 1x HDMI | 1x LAN (RJ45) port(s) | 1x 5Gb/s port(s) USB Type-C | 2x USB 3.1 Gen 2 (teal blue)Type-A | 2x USB 3.1 Gen 1 (blue) Type-A | 2x USB 2.0 | 3x Audio jack(s)

Multi-GPU

AMD CrossFireX™
